4 Head cnc mortising machine with dual tables – KW 1500 4T is the optimal solution for furniture workshops requiring mass production of slot mortises with high precision and outstanding productivity. Featuring 4 independent milling spindles, the machine allows for the simultaneous processing of 4 workpieces, while the dual-table design minimizes stock loading downtime, significantly enhancing production efficiency.
Features of 4 Head cnc mortising machine with dual tables – KW 1500 4T
Dual Independent Table Design: Provides exceptional flexibility during the machining process, easily handling a wide variety of joints such as oval mortises, round mortises, profile milling, etc.
Simultaneous 4-Workpiece Machining: Processes 4 workpieces at the same time to optimize processing cycles and visibly enhance production output.
High-Power Spindles: Equipped with powerful 3.7kW motors with a rotational speed of up to 18,000 RPM, perfectly meeting the requirements for heavy-duty and high-precision milling.
Full Servo Drive Axes: All X, Y, and Z axes utilize servo motors, ensuring high-precision, stable, and durable motion control throughout continuous operation.
Specifications of 4 Head cnc mortising machine with dual tables – KW 1500 4T
| Maximum Working Length | 1500 mm |
| Maximum Working Width | 140 mm |
| Maximum Working Thickness | 200 mm |
| Spindle Motor | 3.7 kW × 4 |
| Spindle Speed | 18000 rpm |
| X-axis Servo Motor | 2 kW |
| Y-axis Servo Motor | 1.3 kW |
| Z-axis Servo Motor | 0.85 kW |
| Total Power | 19 kW |
| Voltage | 380V/50Hz |
| Air Pressure | 0.5 – 0.7 MPa |
| Weight | 1750 kg |
| Machine Dimensions (L × W × H) | 2600 × 2400 × 2300 mm |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
Top selling related slot mortising machine recommendations today
If you are looking for a slot mortising machine that fits your production needs there are several highly popular choices on the market today thanks to their stable operation high precision and excellent capability to handle complex joint processing requirements
Invest in advanced mortising machinery today to optimize your production process
In a context where the furniture industry increasingly demands high precision and processing speed, investing in advanced slot mortising machinery is no longer just an option but has become an essential requirement. Modern CNC machinery lines not only help boost productivity but also ensure consistency and joint quality in every single product detail.
Contact Quoc Duy today for in-depth consultations and to receive detailed price quotes:
- Email : info@quocduy.com.vn
- Hotline : +84 903 600 113
You are also welcome to visit our showroom and experience the machine in operation at: 401 To Ngoc Van Street, Thoi An Ward, Ho Chi Minh City, Vietnam.
