cnc tenoner machine SM T4X4 5200DX
Introduce of tenoner machine
Features of tenoner machine
- The state-of-the-art workpiece clamping system holds the workpiece firmly in place during machining for high precision without disturbing the workpiece.
- Processing 4 workpieces at the same time saves time, high productivity, 16 flexible rotating tool heads.
- All components are selected from famous brands.
- User-friendly interface, easy and fast operation.
Functions of tenoner machine
- Flexible end-to-end machining, fast negative mortise milling, and just serving all customer requirements.
- The high-speed mortising drill milling motor, especially, can adjust the rotational speed to produce the product according to the processing purpose.
- Wide working table width, can process workpieces up to 5000mm in length.
- The lead screw drive mechanism increases the accuracy of workpiece machining.
- Products after processing are always consistent in quality.
Specifications of tenoner machine
| No.of spindle | : 4 axis ( X,Y,Z,A) |
| Motor power | : 5.5 Kw x 4, 3 Kw x 4 |
| Max processing length | : ≤5000mm |
| Max processing thickness | : 100 mm |
| Max processing width | : 145 mm |
| Max processing height | : 200 mm |
| Spindle speed | : 10000-18000 rpm (adjust) |
| Total power | : 28 kw |
| Operating voltage | : 380V |
| Working pressure | : 0.6mps |
| Net weight | : 5500kg |
| Machine size | : 6000 x 2100 x 2480mm |
See more: Automatic feeding and processing center
