CNC router machine – TINY 5 AXIS TC4
Features of CNC Router Machine
- The five-axis machining center can process spatial curved surfaces, special shapes, and complex workpieces through mechanized processing, quickly improving processing efficiency and shortening the processing process.
- Five-axis linkage can process various rotating surfaces and is suitable for large-scale three-dimensional curved surface processing;
- Tool changing in seconds (switching between tool heads in less than 1 second) improves the quality of processed products and processing efficiency;
- It can process flat surfaces, curved surfaces, inclined surfaces, oblique holes, two- and three-dimensional curved surfaces and three-dimensional lines. The workpiece blank is clamped and positioned at one time, and five-axis linkage milling, engraving, drilling, sawing and other functions can be realized in all directions in the five-dimensional space;
- Used for roughing and finishing of complex workpieces such as solid wood and special shapes;
Specifications of CNC Router Machine
| X axis : | Max. processing width of single table : 680mm × 2 |
| Max. processing width of double table linkage : 1450mm | |
| Y axis : Max. processing length | : 1700mm |
| Z axis : Max. processing height | : 550 mm |
| Maximum speed | X axis : 45m/min |
| Y axis : 45m/min | |
| U axis : 45m/min | |
| Z axis : 45m/min | |
| Rotation axis | A axis (rotating head) : continuous rotation |
| C axis (rotating head) : ±380° | |
| Spindle power | : 7.4KW × 1pcs -24000rpm |
| : 4.5KW × 1pcs – 18000rpm | |
| Inverter | 7.5kw x 1pcs , 5.5kw x 1pcs |
| Operating Voltage | : 380V×3P |
| Electricity supply | : 380V/50HZ |
| Install power input | : 30KW |
| Intake pipe | : 16mm |
| Incoming cable | : 15mm² |
| Compressed air pressure | : 6 bar |
| Installation dimensions | : 3600×2800×3100mm |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
