Dual head cnc mortising machine with horizontal drilling – KW 1800MD is the optimal solution for furniture workshops that require fast and precise mortising. With a flexible dual-head design, the machine enables efficient processing of product components while integrating a horizontal drilling function, providing versatility and significantly shortening processing time.
Features of Dual head cnc mortising machine with horizontal drilling – KW 1800MD
Intuitive Control Panel: Designed with an intuitive, user-friendly control panel that makes operations simple and highly efficient.
High-Flexibility Motion System: The X, Y, and Z 3-axis motion system operates smoothly with fast processing speeds, combining with the horizontal drilling unit to deliver high flexibility during machining.
Heavy-Duty Frame Design: Built with a rigid and robust frame structure that minimizes vibration, ensuring stable operation and long-term durability over time.
Specifications of Dual head cnc mortising machine with horizontal drilling – KW 1800MD
| Maximum X-axis Travel | 2500 mm |
| Maximum Y-axis Travel | 440 mm |
| Maximum Z-axis Travel | 150 mm |
| Spindle Motor | 4.5 kW × 2 |
| Spindle Speed | 18000 rpm |
| Drilling Motor | 2.2 kW |
| Working Air Pressure | 0.6 MPa |
| Voltage | 380V/50Hz |
| Weight | 1800 kg |
| Machine Dimensions | 3650 × 1260 × 1750 mm |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
Operating video of DUAL-HEAD CNC MORTISING MACHINE WITH HORIZONTAL DRILLING – KW 1800MD
