Panel cross-cutting machine – KW J700 features a cutting width capacity of up to 700 mm, making it ideal for processing solid wood strips and panel boards in edge-glued panel and solid wood furniture manufacturing plants. Designed for fast, highly stable cutting, the machine reliably satisfies diverse machining requirements while significantly boosting production throughput.
Features of Panel cross-cutting machine
Capable of processing timber slats and large-format panel boards with a maximum cutting width of up to 700 mm, satisfying diverse production demands.
Equipped with a high-clarity touchscreen control panel featuring an intuitive interface for effortless setup and parameter adjustments by operators.
Integrated with a material pusher and workpiece hold-down system, enabling rapid positioning and clamping to significantly boost machining speed and throughput.
Specifications of Panel cross-cutting machine
| Max. Cutting Length | : 2440mm |
| Working Width | : 700mm |
| Working Thickness | : 80mm |
| Cutting Motor Power | : 7.5 kW |
| Saw Blade Diameter | : 305mm |
| Saw Blade Bore Diameter | : 30mm |
| Saw Blade Speed | : 5.600 rpm |
| Saw Carriage Forward Speed | : 15m/min |
| Saw Carriage Return Speed | : 60m/min |
| Feeding Servo Motor | : 1 kW |
| Machine Control | : Touchscreen |
| Machine Weight | : 2,500 kg |
| Voltage | : 380V |
| Machine Dimensions | : 4000 x 2200 x 1700 mm |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities
View more: Intelligent optimizing rip & cross-cut line (scan – rip – scan – cross-cut) – SDC Z16
VIDEO Panel cross-cutting machine
Latest quotation for Panel cross-cutting machine
To receive an accurate price quote for a panel cross-cutting machine, businesses should specify workpiece dimensions, material thickness, target production output, and automation requirements. Based on these details, Quoc Duy can recommend the ideal machine model and configuration to optimize your investment costs.
With over 23 years of expertise in woodworking machinery supply, Quoc Duy is committed to delivering high-quality, competitively priced wood sawing solutions.
