Optimizing cut off machine – SC 230S is equipped with multiple flexible cutting modes to meet diverse processing requirements. It effectively reduces processing time and labor costs while driving up manufacturing efficiency and overall economic returns for your business.
Features of Optimizing Cut Off Machine
A profitable performer for safe, high speed and high efficiency production.
A wide variety of cutting modes to meet your flexible cutting requirements.
Lower labor cost and time cost! Increase production efficiency and economic benefits!
- This machine uses a fluorescent crayon for marking, incorporated with a photocell sensor to detect defective parts automatically.
- High performance AC servo motor drives the infeed conveyor system, providing precise positioning of the workpiece. *Multiple language displays : Chinese, English and other languages(Option).
- Various lengths and quantities of cut can be set as desired. Data can be memorized.
- (36 sizes in a Job Sheet. Total 100 Job sheets) *Variety of cutting modes to meet your flexible cutting requirements.
- SC-230A : Sawblade elevation by Air Cylinder. SC-230W: Sawblade elevation by Servo motor.
Specifications of Optimizing Cut Off Machine
| Cutting Thickness | 12 – 75 mm |
| Cutting Width | 20 – 230 mm |
| Minimum Cutting Length | 50 mm |
| Minimum Infeed Workpiece Length | 260 mm |
| Minimum Workpiece Cross Section | 30 × 12 mm |
| Maximum Workpiece Cross Section | 230 × 40 mm / 160 × 75 mm |
| Maximum Feed Speed | 150 m/min (Pneumatic Cylinder) |
| Maximum Feed Speed (Servo Option) | 190 m/min |
| Cutting Capacity | 138 pcs/min (Pneumatic Cylinder) |
| Cutting Capacity (Servo Option) | 185 pcs/min |
| Saw Blade Diameter | Ø505 mm (20″) |
| Saw Arbor Diameter | Ø25.4 mm (1″) |
| Spindle Speed | 4000 rpm |
| Feed Motor Power | 10 HP (7.5 kW) |
| Saw Drive Motor Power | 10 HP (7.5 kW) |
| Outfeed Motor Power | 1 HP (750 W) |
| Lifting Motor Power | 1/4 HP × 2 |
| Working Air Pressure | 5 – 6 kg/cm² |
| Dust Collection Port Diameter | Ø125 mm (5″) × 3 |
| Machine Dimensions | 19600 × 1862 × 1750 mm |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities
View more: CNC high speed cut off saw – SMVK J603
Latest Optimizing Cut Off Machine Price
To receive an accurate quotation and recommendation for the most suitable Cross-Cut Saw or Defect Optimizing Saw, simply provide us with the following details:
Desired Production Capacity
Factory / Workshop Floor Area
Existing Machinery Line & Setup
Wood Species & Workpiece Dimensions
Target Investment Budget
Quoc Duy will deliver a tailored solution designed to maximize your return on investment and elevate overall production yield.
