Optimizing moveable multiple rip saw GRS 460M marks laser cutting lines specifically used to cut boards, cut edges, and cut defects.
Introduction of optimizing moveable multiple rip saw
Features of optimizing saw machine
- Laser cutting line marking: fixed and moving lines
- Optimize cutting paths, determine cutting with priority lines
- Perform cutting lines: chipboard, edge cutting, defect cutting
Structures of optimizing cut off saw
The saw blade moves according to the laser. The machine has a total of 4 blades, of which 2 blades are fixedly positioned on both sides of the workpiece.
Line A cut size will be placed inside of the line. For B series, the cut size will be placed outside of the line.
The sawing machine uses lasers to mark cutting lines on wooden panels. The machine will cut according to this set line, the size changes depending on the operator’s wishes.
With 2 lasers fixed at the edge area, it is possible to minimize waste products at both edges of the workpiece, as well as areas with errors.
Specifications of optimizing moveable multiple rip saw
| Sawblade Diameter | Ø 405 (16”) / 115 mm, Ø 355 (14”) / 90 mm |
| Max. Cutting Thickness | Ø 305 (12”) / 65 mm, Ø 254 (10”) / 40 mm |
| Min. Cutting Thickness | 12 mm |
| Max. Cutting Width | 460 mm |
| Max. infeed width | 785 mm |
| Min. Cutting Length | 690 mm |
| Feeding speed | 10~40 m/min |
| Chain Width | 490 mm |
| Sawblade keyway | 20 mm x 2 |
| Distance between keyways | 80 mm |
| Sawblade spindle diameter | Ø 55 mm |
| Spindle speed | 3800 rpm |
| Saw drive motor | 50 HP |
| Feed motor | 3 HP |
| Pressure rollers elevation motor | 1/2 HP |
| Saw arbor elevation motor | 1/4 HP |
| Saw arbor movable servo motor | 1 HP x 1~4 |
| Dust hood outlet diameter | Ø 150 mm (6”)*2 |
| Table height from floor | 890 m |
| Machine size | 2000 x 1810 x 3115 mm |
