Double end miter saw TDS 4
Introduction of double end miter saw
Feature
Hand operated clamping and feeding of stock.
Performs double end cut off operation at a time.
Each head is independently controlled.
Sawhead swivels 360°.
Sawblade not included.
Specifications
CAPACITY | Carriage | SINGLE RAIL |
Max. cutting length | 48″ | |
Min. cutting length | 12″ | |
Cutting width | 24″ | |
Max. clamping thickness | 4-1/2″ | |
SAW | Sawblade diameter | 8″/10″/12″ (optional) |
Saw arbor | Ø 1″ | |
Sawblade speed | 3400 R.P.M. | |
Sawblade swivel | 360° | |
TRAVERSE | Saw longitudinal travel | 12″ |
Saw vertical travel | 17″ | |
Carriage cross travel | 24″ | |
MOTOR | Sawhead drive motor | 2 HP x 2 |
SHIPPING | N.W. / G.W. | 500/ 580 kgs |
Machine dimensions | 88″×68″×53″ | |
Packing dimensions | 88″×24″×59″ |
