Quoc Duy offers a TDS 6 Double end miter saw machine, which is a wood cutting machine with two heads. This machine is easy to operate and maintain, and cleaning it is also hassle-free. If you want to learn more about the 2-head wood-cutting machine product line, join Quoc Duy to get a detailed understanding of it.
Feature of Double end miter saw machine
- Double end miter saw Taiwan machine is designed to help you save time during production. It features a fast cutting speed and allows for continuous workpiece loading.
- The double end miter saw machine is an improvement over previous models, with a maximum cutting length of 1829mm, making it suitable for many products with different cutting specifications.
- Operating, cleaning, and maintaining the machine is simple and easy. The TDS-6 automatic double end saw machine is specialized for cutting 2 ends of board edges continuously, with a saw blade angle of 360 degrees.
Specifications of Double end miter saw machine
| Carriage | : double rail |
| Max length of cut | : 1829 mm |
| Min length of cut | : 305 mm |
| Max width of cu | : 610 mm |
| Max clamping thickness | : 114 mm |
| Sawblade diameter | : 203/254/305 mm |
| Saw arbor | : Þ 25.4 mm |
| Sawblade speed | : 3400 rpm |
| Sawhead swivel | : 3600 |
| Moulder spindle diameter | : Þ 25.4 mm |
| Spindle speed | : 3400rpm |
| Spindle swive | : 3600 |
| Saw longitudinal travel | : 305 mm |
| Saw vertical travel | : 432 mm |
| Carriage cross travel | : 610 mm |
| Sawhead drive | : 2 HP x 2 |
| Net weight | : 750 kgs |
| Gross weight | : 900 kgs |
| Machine dimensions | : 2845 x 1295 x 1143 mm |
| Packing dimensions | : 2845 x 813 x 1499 mm |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
View more: automatic double ended tenoners – RH 66A
Latest double end miter saw machine price
If you require consultation and installation services for your woodworking or painting production machinery, our experienced team at Quoc Duy, with over 23 years of industry experience, can guarantee the best quality for your products.
To inquire about our sawing machine, please get in touch with us through any of the following channels for a quick consultation and quote:
- Email : info@quocduy.com.vn
- Hotline : +84 903 600 113
You are also welcome to visit our showroom and experience the machine in operation at: 401 To Ngoc Van Street, Thoi An Ward, Ho Chi Minh City, Vietnam.
