The 4 spindle 16 tools CNC machine is the ideal solution for milling and turning table legs, chair legs, bed slats, etc. It perfectly handles diverse models and complex shapes that demand high precision and superior aesthetic quality.
Key Features of the 4 Spindle 16 Tools CNC Machine
Specially designed for machining table legs, chair legs, and export-quality furniture.
Integrates multi-functional capabilities including milling, turning, and engraving to process complex profiles with high precision.
Engineered with 16 tool heads and 1 worktable to efficiently process 4 workpieces simultaneously.
Supports multiple tool installations, saving processing time and maximizing overall productivity.
Technical Specifications
| Maximum processing length | 1200 mm |
| Maximum processing width | 250 mm |
| Distance between spindles | 300 mm |
| X-axis travel | 800 mm |
| Y-axis travel | 1700 mm |
| Z-axis travel | 500 mm |
| Processing speed | 10 m/min |
| No-load travel speed | 25 m/min |
| Motor power | 5.5 kW x 4; 3.7 kW x 4 |
| Spindle speed | 12,000 RPM |
| X-axis servo motor | 2.0 kW |
| Y-axis servo motor | 0.85 kW |
| Z-axis servo motor | 0.85 kW |
| A-axis servo motor | 1 kW |
| B-axis servo motor | 0.75 kW |
| Voltage | 380V / 50Hz |
| Air pressure | 0.6 – 0.8 MPa |
| Total power | 32.5 kW |
| Machine weight | 3800 kg |
| Machine dimensions | 3170 x 2950 x 2550 mm |
Note: Technical specifications, design features, and machine color are subject to change without prior notice, provided that such changes do not affect the functionality and operational performance of the machine.
video about 4 spindle 16 tools cnc machine
Latest Price Quote for the 4 Spindle 16 Tools CNC Machine
Quoc Duy is a leading provider of woodworking machinery with over 21 years of market experience. We are proud to be a reputable supplier with a strong presence across Vietnam and many countries worldwide, including Laos, Thailand, Cambodia, India, Panama, Australia, and more. Backed by a highly experienced technical team that continuously updates and adopts modern technologies, Quoc Duy consistently delivers premium, high-tech, and cost-effective woodworking machinery, particularly our 16-axis 4-spindle CNC machine lines.
For inquiries regarding woodworking machinery, please contact us at 0903 600 113 for the fastest consultation and price quotes. Furthermore, a wide range of machines is always available at Quoc Duy’s warehouse for clients to experience and test run before making an investment decision. Visit us today at: 401 To Ngoc Van, Thoi An Ward, Ho Chi Minh City.
