Panel saw machine taiwan TPS 10CH
Introduction of panel saw machine taiwan
Specifications
| Max. cutting length | 3200 mm |
| Max. cutting height | 0 – 100 mm |
| Main sawblade diameter | Ø 405 mm |
| Main sawblade speed | 3910 rpm |
| Arbor diameter | Ø 60 mm |
| Scoring sawblade diameter | Ø 176 mm |
| Scoring sawblade speed | Ø 45mm |
| Scoring sawblade speed | 5100 rpm |
| Forward speed | 5 – 100 m/min |
| Return speed | 120 m/min> |
| Main sawblade motor | 20 HP |
| Scoring sawblade motor | 3 HP |
| High pressure blower motor | 3 HP |
| Automatic feed motor | 2 Kw ( AC servo) |
| Pusher feed speed | 5-80 m/min |
