NOLINE straight edge banding machine – CB 360J ARC
Functions of NOLINE straight edge banding machine – CB 360J ARC
Pre-milling
Gluing & IR Heating
Edge Pressing Rollers
End Trimming
Top & Bottom Fine Trimming
Corner Rounding
Glue Scraping
Cleaning Liquid Spraying System
Buffing
Specifications of NOLINE straight edge banding machine – CB 360J ARC
| Straight edge milling motor | : 1.8 kW x 2 |
| End trimming motor | : 0.37 kW x 2 |
| Top/bottom straight trimming motor | : 0.75 kW x 2 |
| Corner rounding motor | : 0.3 kW x 2 |
| Buffing motor | : 0.37 kW x 2 |
| Pressure roller conveyor motor | : 0.75 kW |
| Table lifting motor | : 0.37 kW |
| Conveyor motor | : 5.5 kW |
| Glue roller motor | : 0.75 kW |
| Thread winding motor | : 0.75 kW |
| Working speed | : 11m/min |
| Working thickness | : 12 – 25 mm |
| Edge band thickness | : 0.4 – 3 mm |
| Workpiece width | : ≥ 80 mm |
| Air pressure | : 0.6 – 0.8 MPa |
| Voltage | : 380V/50Hz |
| Machine dimensions | : 8400 x 800 x 1600 mm |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
