CNC dual rotary table machine 6 flip tables – KW T4X4 24S
Features of CNC Dual Rotary Table Machine 6 Flip Tables
- The machine is designed to process various types of wood and plastic materials with a 4-axis, 16-tool system combined with a flip table to accelerate processing time.
- The flexible cable management enhances smooth operation during machine runtime.
- Equipped with a conveyor system to remove waste material, optimizing processing efficiency and improving workplace safety.
- The sturdy frame ensures stability throughout operation.
- Processed products consistently maintain high quality.
Specifications of CNC Dual Rotary Table Machine 6 Flip Tables
| X-axis travel | : 5500mm |
| Y-axis travel | : 650mm |
| Z-axis travel | : 500mm |
| X-axis speed | : 50m/min |
| Y-axis speed | : 25m/min |
| Z-axis speed | : 25m/min |
| Spindle spacing | : 280mm |
| Spindle motor power | : 5.5kW x 4 + 3.7kW x 4 |
| Maximum machining length | : 5000mm |
| Maximum machining width | : 170mm |
| Maximum machining thickness | : 60mm |
| Spindle speed | : 12000 – 18000 rpm |
| X-axis servo motor power | : 2kW x 2 |
| Y-axis servo motor power | : 2kW |
| Z-axis servo motor power | : 1.8kW |
| B-axis servo motor power | : 0.85kW |
| A-axis servo motor power | : 400W x 24 |
| Voltage | : 380V |
| Machine size | : 7500x2700x2720mm |
| NET Weight | : 5600kg |
Attention: Specifications, design features and colors of the machine are subject to change without prior notice, but will not affect the function and operation of the machine.
