Automatic laser logo marking machine
Features of Automatic laser logo marking machine
High-Speed Galvo Scanner Head: Minimizes latency and significantly increases processing speed.
German-Imported Mirrors: Compact design offering high precision and durability.
Superior Beam Quality: Low power loss with uniform beam distribution for sharp and consistent results.
Broad Graphic Format Compatibility: Supports multiple file formats, including AI, DXF, BMP, JPEG, PLT, and more.
Specifications of Automatic laser logo marking machine
| Laser Wavelength | 10.6 μm |
| Beam Quality | < 1.2 M² |
| Pulse Frequency | 0 – 25 kHz |
| Laser Power | 30 W |
| Cooling Method | Air Cooling |
| Line Width | 0.1 mm |
| Laser Spot Size | 1.5 mm |
| Processing Speed | 0 – 10000 mm/s |
| Power Supply | 220V / 50Hz |
| Total Installed Power | 1.75 kW |
| Dimensions | 1120 × 820 × 1650 mm |
| Weight | 258 kg |
| Operating Environment | Temperature: 10 – 35°C; Humidity: 5 – 85% (Non-Condensing, Dust-Free or Low-Dust Environment) |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities
View more:
Quotations for Automatic laser logo marking machine
To receive a quick consultation and quotation for our Automatic Laser Logo Marking Machine, please contact Quoc Duy today. Our team is ready to answer all your inquiries.
Alternatively, you can leave your requirements in the live chat box, and we will respond immediately.
- Email : info@quocduy.com.vn
- Hotline : +84 903 600 113
You are also welcome to visit our showroom and experience the machine in operation at: 401 To Ngoc Van Street, Thoi An Ward, Ho Chi Minh City, Vietnam.
