Auto double side copy shaping machine HH-85-4TA
Introduction of auto double side copy shaping machine
Feature
– Designed to replace a manually operated double spindle shaper, this four-head automatic double side copy shaping machine provides high production capacity.
– Operation is controlled by a PLC for maximum convenience.
– Cutterheads built at both sides of the machine allow for cutting curved profiles with no tearing problems.
– Automatic workpiece infeed and product outfeed greatly increase working efficiency.
Specification
| Working capacity | 1500 x 360 x 140 mm |
| Main spindle power | 7.5 HP x 2 – 5 HP x 2 |
| Main spindle diameter | 40 mm |
| Hydraulic power | 3 HP |
| Revolution speed | 9500 rpm |
| Required air pressure | 6 kg/ cm3 |
| Machine size | 5000 x 2080 x 1950 mm |
| Packing size | 5140 x 2200 x 2060 mm |
| Net weight | 2880 kg |
| Gross weight | 3290 kg |
