The 2 Head Veneer Sanding Machine is a high-performance sanding line capable of rapid processing, effectively sanding and polishing wood workpieces with high efficiency.
Detailed Introduction of the 2 Head Veneer Sanding Machine
Outstanding Features of the Veneer Sanding Machine:
Highly flexible processing capabilities.
Compact and space-saving machine dimensions.
User-friendly and effortless machine operation.
Technical Specifications of the 2 Head Veneer Sanding Machine:
| Max. working width | 1300 mm |
| Min. working length | 380 mm |
| Working thickness | 3 – 100 mm |
| Feeding speed | 5 – 26 m/min |
| Sanding belt size | 1330 x 2200 mm |
| 1st spindle motor power | 11 kW |
| 2nd spindle motor power | 7.5 kW |
| Feeding conveyor motor power | 3 kW |
| Working pneumatic pressure | 0.6 MPa |
| Voltage | 380V / 50Hz |
| Air consumption | 17 m³/h |
| Overall dimensions | 2112 x 2634 x 2100 mm |
| Machine weight | 3900 kg |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice; however, this will not affect the core functionality and operational performance of the machine.
