Vertical band resaw hydraulic system TF 900
Introduction of vertical band resaw hydraulic system
Specifications
| Cutting capacity | : 550 x 550 mm |
| Distance from fence to blade | : 230 mm |
| Distance from feed roller to blade | : 320 mm |
| Wheel diameter | : 36″ |
| Wheel width | : 3-1/2″ |
| Width of blade | : 4″ |
| Length of blade | : 5760 mm |
| Feed speed (Variable) | : 37 M/min |
| Wheel drive motor | : 15-20 HP |
| Hydraulic pump motor | : 2 HP |
| Net weight | : 2000 kgs |
| Gross weight | : 2200 kgs |
| Machine size | : 2550 x 1510 x 2250 mm |
Features
Automatic Features and Construction:
• The feed speed is operated by a hydraulic system which makes the machine suitable for cutting various types of lumber.
• Feed rollers’ movements are actuated by an air and hydraulic combination system.
• The feed rollers can be switched to an automatic or semi-automatic system. It can save more time when works are cutting different sizes of lumber.
• The power elevation of the upper wheel makes users easy to replace the blade. A handwheel is also provided for micrometrical adjustment.
General Features and Construction:
• Moving workplaces easily, it doesn’t need to build up a foundation.
• The saw tension can be read from the tension indicator.
• A principle of counterbalance weight controls the blade tension.
• A handwheel is also provides for micrometrical adjustment.
• Bakelite of saw guide ensures a high wear resistance.
• The high speed steel upper wheel and the casting iron lower wheel both are dynamically balaneed that makes the machine run extremely smooth.
• Bronze pieces are provided for wheel cleaning.
