Sliding table saw taiwan P 32 is specifically designed for cutting flat wooden blanks, with a sturdy structure ensuring stable operation.
Features of Sliding table saw Taiwan
- This sliding table saw is imported directly from Taiwan and is perfect for sawing and cutting industrial boards such as MDF, MFC, HDF, and Okal.
- The saw is designed with two cranks on the front of the body: one to tilt the blade and one to open the saw blade.
- Additionally, the sliding table saw Taiwan for HDF is equipped with a protective cover that helps protect the saw blade for the operator’s safety and vacuums out dust to clean the saw blade.
Specifications of Sliding table saw Taiwan
| Sliding table dimension (mm) | 380 x 3200 |
| Main saw blade (mm) | 305 |
| Main saw bore(mm) | Ø 25.4 |
| Scoring saw blade(mm) | Ø 120 |
| Scoring saw blade bore(mm) | Ø 22 |
| Max cutting height with blade at 900 (mm) | 105 |
| Max cutting height with blade at 450 | 73 |
| Main motor power | 7.5 HP |
| Main blade speed (rpm) | 3000/ 4000/ 5000 |
| Scoring motor power (HP) | 1 |
| Scoring blade speed(rpm) | 8000 RPM |
| Cutting width adjustment | MANUAL |
| Saw table extension(mm) | 370 mm |
| Blade tilting adjustment | 0- 450 MANUAL |
| Main saw height adjustment | MANUAL |
| Scoring saw height adjustment | MANUAL |
| Scoring saw +/- direction adjustment | MANUAL |
| Blade tilting show | Take the machine |
| Main blade speed show | Puly change |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
View more: UNIVLAERSAL CIRCUR SAW – YL 551
VIDEO OF TAIWAN SLIDING TABLE SAW OPERATION
Some notes when using Taiwanese 2-blade sliding table saw
- To ensure a longer life for the saw blade and a safer working environment, it is recommended to raise it about 10-15mm above the board distance.
- Also, it is important to adjust the saw blade speed accordingly and install the main and auxiliary saw blades running in opposite directions.
- It is crucial not to block the saw blade with any objects and to choose a high-quality saw blade with good sharpness.
- Any saw blade that is bent, cracked, or chipped should not be used.
- The protective shield and dust collector should be set at the appropriate height to avoid any obstruction.
- When operating the saw, operators must follow specific instructions and dress neatly.
- Finally, it is essential to clean the machine and saw blade after use.
Latest Sliding table saw Taiwan price
We are a top provider of woodworking machines, offering machines imported directly from Taiwan, Europe, and the SEMAC brand.
For quick access to up-to-date machine prices and consulting information through the Quoc Duy chainsaw system, customers can contact us directly through the following channels:
- Email : info@quocduy.com.vn
- Hotline : +84 903 600 113
You are also welcome to visit our showroom and experience the machine in operation at: 401 To Ngoc Van Street, Thoi An Ward, Ho Chi Minh City, Vietnam.
