MDF wood grain printing machine – TDP 1320 is specifically engineered to apply high-fidelity wood grain patterns onto MDF boards rapidly and precisely. Machine operation is straightforward and seamless via an intuitive touchscreen interface.
Features of MDF wood grain printing machine – TDP 1320
Lifting & Positioning System: Features a high-precision automatic deceleration lifting mechanism, comprising a heavy-duty lifting plate and support struts. The lifting base is fully adjustable to accommodate various panel thicknesses.
Paint Recovery & Recirculation System: Equipped with a premium 4-point Taiwan-imported pneumatic pump system. Utilizes a dual-pump configuration integrated with a heavy-duty stainless steel heating tank.
User Interface & Control: Features a user-friendly and responsive touchscreen display for effortless operational adjustments.
Shihlin Inverter: Integrated with high-performance Shihlin variable frequency drives (VFD) for precise motor speed control.
Specifications of MDF wood grain printing machine – TDP 1320
| Working Area | 2500 × 1300 mm |
| Printing Gap | 30 mm |
| Maximum Working Height | 350 mm |
| Printing Speed | 18 m²/h |
| Printhead | Ricoh G6 (Japan) |
| Print Resolution | 1440 × 1440 DPI |
| Printhead Width | 54.1 mm |
| Number of Nozzles | 1280 (4 × 320 Channels) |
| Nozzle Resolution | 600 DPI |
| Supported Ink Types | UV, Solvent, Aqueous |
| Maximum Jetting Frequency | 50 kHz |
| Droplet Size | 5 – 15 pl |
| Supported Ink Viscosity | 10 – 12 mPa·s |
| Weight | 1000 kg |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
Operation Video MDF WOOD GRAIN PRINTING MACHINE – TDP 1320
Recommended alternative wood grain processing machinery
If you have not yet found the ideal machinery line for your specific production needs, we highly recommend exploring our other related equipment options below: Single Side Embossing Machine Wood Grain – SMBY 1320GP, wood surface wire brushing machine,….
Where is the most reliable supplier to invest in MDF wood grain printing machine – TDP 1320 ?
Quoc Duy stands as one of the premier woodworking machinery suppliers in Vietnam. We possess over 23 years of industry experience and have successfully delivered numerous large and small-scale projects for domestic and international furniture factories. If you are looking for a partner you can fully trust, Quoc Duy is your ultimate choice.
Should you require deeper product insights or wish to receive pricing quotations for our general woodworking machinery range or specialized wood grain texturing lines, please contact us via:
- Email : info@quocduy.com.vn
- Hotline : +84 903 600 113
You are also welcome to visit our showroom and experience the machine in operation at: 401 To Ngoc Van Street, Thoi An Ward, Ho Chi Minh City, Vietnam.
