Andi cojet plus digital printing machine COJET
Introduction of andi cojet plus digital printing machine
Features
– Print Heads Konica Minolta 512 nozzles (4 heads, up to 10 heads optional).
– Print Color C, M, Y, K, Lc, Lm, White Ink, (top coat ink optional).
– Ink Type UV Curable ink.
– Media Handling Flatbed moving gantry, Vacuum.
– Media Type Foam Board, Acrylic sheet, Glass, Wood, Aluminium, Tile, etc.
– Interface Ethernet 10/100 Base T.
– RIP application As RIP support.
Specifications
| Print Heads | Konica Minolta 512 nozzles (4 heads, up to 10 heads optional) |
| Drop Volume | 14pl |
| Print Color | C, M, Y, K, Lc, Lm, White Ink, (top coat ink optional) |
| Print Resolution (dpi) | 720 x 720 1440 x 720 |
| Print Speed, m2/hr (ft2/hr) | 6/7 colors 4 colors 6/7 color 4 color |
| Up to m2/hr (ft2/hr) | 14.1 (150) 28.2 (301) 7.1 (75) 14.2 (150) |
| Print Area | 2350 mm x 1250 mm (96 inch x 48 inch) |
| Max. Thickness | 100mm (3.94 inch) |
| Ink Type | UV Curable ink |
| Media Handling | Flatbed moving gantry, Vacuum |
| Media Type | Foam Board, Acrylic sheet, Glass, Wood, Aluminium, Tile, etc. |
| Interface | Ethernet 10/100 Base T |
| RIP application | As RIP support |
| Dimension | 4600 mm x 3750 mm x 2000 mm |
| Weight | 2500 Kg |
| Package List | CoJet – 2612s Printer system, Maintenance Tools, Power Cable, ink, Vacuum Pump, Communication Cable, Operation Manual |
| Operation Environment | Temperature: 15-30° C (59-86° F), Humidity: 30-70% RH |
| Power Requirement | 200-240 VAC, 50/60 Hz, 32A, 3 Phase |
| Air Source | 5kg/cm, 30 L/min, Clean Dry Air |
| Warranty | Máy in: 1 Year, Đầu in: 6 months |
