Inclined edge banding machine – SMBL 450DT is widely used in the production of industrial board furniture. Applying gluing to the edges of cabinet doors and shelves to minimize accessories. With the principle of self-beveling and gluing, the machine brings outstanding productivity to businesses.
Features of auto inclined edge banding machine
- The inclined edge banding machine is specialized for gluing edges of wood, MDF, oak, plywood, MFC, MDF or cabinet edges, bed edges, tables, and chairs…
- With the 45-degree edge milling feature and splint slotting feature, gluing a part at an angle improves the finished product without blemishes.
- Combining 9 functions on the same machine helps create products consistent in quality and aesthetics.
- The machine frame is sturdy and has a precise mechanical structure that is easy to align.
- Touch screen operation is quick – saves time
- Paste the splint with high adhesion, and beautiful seams. Outstanding productivity
- Operates stably continuously for many hours, can paste a series of products without worrying about overheating
Function of auto inclined edge banding machine
- Pre – milling
- Roll glue on the edge of the inclined board
- Glue the straight edge
- Edge tape grooving
- Tape pressing
- End – rough trimming
- Fine trimming
- Scraping
- Buffing
Specifications of auto inclined edge banding machine
| Working thickness | : 25 mm |
| Feed speed | : 10-12 m/min |
| Air pressure | : 6 kg |
| Motor cutting 45° | : 3 kw x 1 |
| Motor end trimming | : 2.4 kw x 2 |
| Milling motor on – below | : 0.75 kw x 2 |
| Polishing motor | : 0.37 kw x 2 |
| Motor feeding | : 2.2 kw |
| Motor lifting | : 0.18 kw x 1 |
| Voltage | : 380/ 220 V – 50 Hz |
| Bevel angle | : 450 |
| Machine size | : 6700 x 1100 x 1600 mm |
| Net weight | : 2200 kg |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities
View more: Straight and angled edge banding machine – SMHC 4590
VIDEO OF OPERATION OF of auto inclined edge banding machine
Latest inclined edge banding machine price
