Double end tenoner robot is a breakthrough improvement in the current wood tenon creation technique. With the ability to automatically sharpen mortise at high speed, it helps create a variety of mortise styles in large quantities and with consistent quality.
Introduction of double end tenoner robot
Outstanding features of the 2-head cnc mortise machine
- Tenon on both ends of the workpiece at the same time
- Can process a variety of tenon types such as double tenon, round tenon, square tenon, oval tenon, elliptical tenon,…
- Fast tenon milling speed, bringing high performance
- Setting tenon parameters is simple and easy
- Equipped with an automatic bar feeding system, helping with continuous processing
- The machine frame is made of cast iron to help increase product accuracy after processing
- The tenoner machine can process with a maximum tilt angle of 45 degrees
- Continuously machining the yin and yang tenons at the same time
- Pneumatic air clamp ensures the workpiece does not fall during machining
- Lead screw drive mechanism increases absolute accuracy during machining
Specifications of double end tenoner robot
| Width of processing material | : 10-120 mm |
| Length of processing material | : 250-2000 mm |
| Thickness of processing material | : 10-80 mm |
| Max. Tenon made size | : 40 mm |
| Vertical adjustable angle | : +46 & -10 degree |
| Horizontal adjustable angle | : +46 & -10 degree |
| Spindle speed | : 9000-12000 rpm |
| Systerm | : Windows 7 |
| Dust suction inlet | : 100×2 & 150 x 1 |
| Feeding system | : Automatic feeder system |
| Spindle motor | : 5.5 KW x 2 |
| Total power | : 23 KW |
| Net weight | : 2500 kgs |
| Machine size | : 4300 x 2300 x 2100 mm |
Video of operating the double end tenoner robot
>> See more: Round end tenon cnc machine
Latest double end tenoner robot price
At Quoc Duy, we take great pride in being a premier supplier of the finest woodworking machine available today. Our range of machines includes various models that are equipped with the latest components imported from Taiwan, Europe, and other countries. Our team of experienced technicians is always available to provide valuable advice and answer any questions you may have.
If you are interested in our round end tenon machine system, please do not hesitate to contact us using the information provided below. We will respond to your inquiry as soon as possible.
- Email : info@quocduy.com.vn
- Hotline : 0903 600 113
- Website : www.quocduy.com.vn – www.semac.com.vn
You are also welcome to visit our factory, located at 401 To Ngoc Van, Thanh Xuan Ward, District 12 in Ho Chi Minh City, to see our machines in action.
