Features of CNC Automatic Jigsaw Machine
- This is a new CNC machine model, developed to replace the edge cutting and dead angle cutting problems of traditional jigsaws, helping to improve the quality of the machined surface.
- Replace the traditional machining method, manual feeding, engraving in the old process, reduce labor costs, reduce work accidents and improve production efficiency.
- Apply CNC technology, support DXF format. Adjust cutting angles, drilling according to needs, easy and simple operation.
Configurations:
- Control system: Taiwan
- Servo motor: Huichuan
- Screw: Taiwan
- Guide rail: ROUST Germany
- Electrical components: Schneider
- Inverter: Fuling
Specifications of CNC Automatic Jigsaw Machine
| Maximum workpiece length | : 2500 mm |
| Maximum workpiece width | : 1250 mm |
| Maximum workpiece thickness | : 0 – 130 mm |
| No-load cutting speed | : 0 – 30 m/min |
| Cutting speed | : 0 – 20 m/min |
| No-load drilling speed | : 0 – 60 m/min |
| Drilling speed | : 0 – 30 m/min |
| Total power | : 30 kW |
| Cutting spindle power | : 18 kW |
| Drilling spindle power | : 11 kW |
| Spindle rotation speed | : 10,000 – 18,000 rpm |
| Milling cutter diameter | : 6 mm / 8 mm |
| Machine dimensions | : 4700 × 4600 × 2660 mm |
| NET weight | : 6000 kg |
Knife set specifications
| Knife length (mm) | Blade length (mm) | Knife Diameter (mm) | Workpiece width (mm) |
| 150 | 80 | Ø6 | 0 – 80 |
| 200 | 130 | Ø8 | 0 – 130 |
Note: The technical specifications, design features, and color of the machine may be subject to change without prior notice, while still maintaining its functionality and operational capabilities.
