Automatic high-frequency door press – KW GJT2813-Y50
Features of Automatic high-frequency door press
High-Frequency Heating: High-frequency heating rapidly cures the glue lines on both top and bottom panels, significantly boosting operational efficiency and productivity. Consequently, there are no limitations on the thickness of the board core or wooden frame.
Automated Control System: Features an automated PLC system paired with an intuitive touchscreen interface for effortless operation.
Premium Components & Diagnostics: Built with premium electrical components from leading brands—including Siemens, Schneider, and Omron—to ensure maximum machine stability. Integrated fault display diagnostics allow for quick and easy troubleshooting.
Automated Infeed & Outfeed System: Equipped with automated infeed and outfeed mechanisms driven by an inverter for precise speed control.
Comprehensive Safety Features: Superior shielding and protective systems ensure maximum safety for both the operator and the equipment.
Flexible Integration: Designed for flexible deployment, the machine can operate as a standalone unit or be fully integrated into an automated production line.
Superior Output Quality: Delivers finished products that meet exceptional quality and high aesthetic standards.
Specifications of Automatic high-frequency door press
| Working Size | 1250 × 2800 mm |
| Top/Bottom Overlay Panel Thickness | 2 – 12 mm |
| HF Power | 50 kW |
| HF Frequency | 6.78 MHz |
| Heating Method | Double-Sided Heating |
| Maximum Pressing Force | 50 T |
| Hydraulic Cylinders | 6 pcs (Ø80 mm) |
| Hydraulic Motor Power | 4 kW |
| Hydraulic Pressure | 16 MPa |
| Infeed Conveyor Table Size | 2850 × 1300 × 800 mm |
| Conveyor Speed | 25 m/min |
| Conveyor Motor Power | 2.2 kW |
| Power Supply | 380V / 50Hz |
| Weight | Approx. 7300 kg |
| Dimensions | 9750 × 2200 × 3600 mm (Including Infeed & Outfeed Conveyor Tables) |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities
View more:
Operation Video AUTOMATIC HIGH-FREQUENCY DOOR PRESS
Quotation for Automatic high-frequency door press
With over 23 years of experience in the woodworking machinery industry, Quoc Duy offers a diverse portfolio of advanced equipment, including 5-axis CNC machining centers, CNC milling and turning lathes, cold presses, high-frequency edge banders/gluing presses, automated coating lines, and auxiliary equipment—providing total solutions that optimize production workflows and maximize operational throughput.
For any inquiries or to request a detailed price quotation for our Automatic high-frequency door press, please contact us using the details below:
- Email : info@quocduy.com.vn
- Hotline : +84 903 600 113
You are also welcome to visit our showroom and experience the machine in operation at: 401 To Ngoc Van Street, Thoi An Ward, Ho Chi Minh City, Vietnam.
