Automatic double surface planer – GT 400B has a straight knife design at a reasonable price and is easy to invest in. Designed with a specialized planing shaft system for straight knives, the machine can process workpieces up to 4 inches wide.
Introduction of automatic double surface planer
Features of automatic double surface planer
Specifications of automatic double surface planer
| Maximum Width Of Cut | 405 mm |
| Maximum Thickness Of Cut | 170 mm |
| Minmum Thickness Of Cut | 8 mm |
| Minmum Lenght Of Cut | 250 mm |
| Knife Nos. On Bottom Cutterhead | 4 |
| Knife Sizes | 405 x 3 x 30 mm |
| Cutterhead Diameter | Ø 101 mm |
| CutterHead Speed | 4000 rpm |
| Variable Feed Speed | 8 – 24 m/min |
| Dust Hood Outlet Diameter | 127 mm x2 |
| Table Surface Area | 482.6 x 2184.4 mm |
| Top Cutterhead Drive Motor | 10 HP |
| Buttom Cutterhead Drive Motor | 7.5 HP |
| Feed Drive Motor | 2 HP |
| Upper Mechanism Elevation Motor | ½ HP |
| Machine Dimensions | 2200 x 900 x 1700 mm |
| Net Weight | 1900 kg |
machine operation video of automatic double surface planer
Structure of 2-sided planer with 4 inches of straight knife
Taiwanese double-sided planer is designed into 2 parts, top and bottom. And these two parts are securely connected together with a system of nuts, lead screws and bolts. Thanks to this design, you can adjust the distance between the two knife axes easily and quickly. Below are details of the 2 parts of the 2-sided rolling planer:
- The upper part of the machine includes: conveyor belt, raw billet roll and calculated billet roll. There are also upper knife shafts, fine blank ballast parts and rough workpiece ballast parts.
- The lower part of the 2-sided planer includes: the lower knife shaft, the workpiece table and especially the mechanism that can change the planing depth.
Some other lines of 2-sided wood planers : DOUBLE SIDE PLANER TAIWAN MACHINE – YA 610AD
Quotation for 4-inch 2-sided wood planer
If you have questions related to the straight knife double-sided planer line, you can contact Quoc Duy directly via:
- Hotline for consultation and quote support 24/7 0903 600 113
- Address to see the machine in direct operation: 401 To Ngoc Van, Quarter 1, Thanh Xuan Ward, District 12, Ho Chi Minh City
- Email: info@quocduy.com.vn
- Visit website: quocduy.com or semac.com.vn to update more latest products from Quoc Duy
Quoc Duy specializes in providing quality, reputable woodworking machines at the best prices. We are always ready to serve you.
