Trimming machine EB 41
Introduction of trimming machine
Features
– Trimming machine EB 41, also known as R-board corner board machine.
– The angular machine is imported directly from Taiwan, the compact design is suitable for workshops that do not have much space.
– Rounded corner machine is equipped with a complete brush polishing system.
Specifications
Max. thickness of workpiece | 55 mm |
Min width of workpiece | 85 mm |
Max. softforming depth | 40 mm |
Min inner curve | 9.5 mm |
Max. edge thickness | 6 x 19 mm |
Motor | 500 W |
Speed | 27000 rpm |
Buffing motor | 1/2 HP |
Machine size | 800 x 700 x 1350 mm |
Packing size | 900 x 800 x 1500 mm |
Net weight | 170 kg |
Gross weight | 230 kg |
