Linear sanding machine with the contour smoothing function to help create beautiful products and smooth and precise sanding lines.
Introduction of linear sanding machine
Features of linear sanding machine
- Linear edge sanding machine perfects all 4 sides SM-TS4W8 branded SEMAC – Quoc Duy.
- With fully automatic operations, the products is uniform in quality and creates beautiful aesthetics for the product.
- The sanding machine has a variety of different profiles, helping to smooth the surface of the product.
- The deformation sanding machine is designed with an independent control cabinet and a touch control screen to help control parameters during the machining process.
Mark S part is 400 type triangle sand
sand head can be tilted from +90° to -45°，can sand white coating and ground coating.
Sponge wheels sand
Brush sander
Profile sand
Specifications of linear sanding machine
1. Belt sanding unit = S triangle sanding
Press module length×width×height
: 150×80×50mm
| Sanding motor | : 2.2kw*4 |
| Oscillation motor | : 0.09kw*4 |
| Pulley | : 200mm |
| Belt size | : 2060×80mm |
| Useful working width | : 80mm |
| Dist suction hood dia. | : Φ100mm |
| Compressed air | : 0.6Mpa, 2.0m3 /hour |
| This unit is build in solid structure composed by steel and cast aluminum, worked by CNC machine tools and it’s tiltable from -45°to + 90 °by manual, the cast iron post with 3-direction adjustable. | |
| Oscillation of the abrasive belt by motor with gearbox | |
| Belt tension on lateral aluminum pulley in order to avoid motor wearing
Sanding pad pushing control by valve and pressure adjustable, forward and backward control by PLC Speed variable control by inverter |
|
2. Brushing sanding W unit
| Sponge wheel size for top and bottom sanding | : Diameter:150mm |
| Sponge wheel size for left and right sanding | : Diameter:100mm |
| Disc motor | : 1.5kw*8 |
| Motor spindle | : Φ25.4mm |
| Paper perimeter × width | : 840×100mm |
| Useful working width | : 100mm |
| Dust suction hood dia. | : Φ100mm |
| Compressed air | : 0.6Mpa,2.0m3 /hour |
| This unit is build in solid structure composed by steel and cast aluminum, worked by CNC machine tools and it’s tiltable from -90°to + 90 °by manual, the cast iron post with 3-direction adjustable | |
| Brush sanding unit motor with reversible rotation, the motor spindle is complete with shaft spanner to clamp easy. | |
| Speed variable control by inverter | |
| This unit is complete with jumping system for go in and out at end of work piece, avoid the end over-sanding | |
3. Specifications of linear sanding machine
| Feeding speed | : 5-32 m/min |
| Feeding table height | : 850 mm |
| Feeding motor | : 4.07 kw |
| Total power | : 25.23 kw |
| Overall size | : 9800 × 1800 × 1600 mm |
| Net Weight | : 4200 kg |
VIDEO OF linear sanding MACHINE OPERATION
Latest linear sanding machine price
- You can see more similar products at website www.quocduy.com.vn – www.semac.com.vn
- For further information, please contact Hotline 0903 600 113 for quick advice and support from Quoc Duy’s staff.
- Email: info@quocduy.com.vn
With more than 20 years of experience in the woodworking machine supply industry, Quoc Duy is confident in providing the best quality products to its customers.
