Cnc router machine with boring unit autoload SM 1325 R1B-AL has a fully automatic drilling and milling process that saves time and labor.
Introduction of cnc router machine with boring unit autoload
Features of CNC router machine with boring unit autoload
Nesting CNC drilling milling machine is a combination of three machines including:
+ Automatic knife cutting and sawing machine
+ Hydraulic lifting table system
+ Conveyor belt out workpiece.
This trio creates a combination of cnc nesting drilling and sawing machines that change knives automatically. Create an automated process from lifting the board with a hydraulic lift table and the product being taken out from the conveyor to the workpiece. With a fully automatic process, the automatic milling and drilling machine is a smart and reliable choice for woodworking businesses.
Specifications of CNC router machine with boring unit autoload
1. Cnc router machine with boring unit
| X axis stroke | : 1300 mm |
| Y axis stroke | : 2500 mm |
| Z axis stroke | : 220 mm |
| Max speed | : 0-60 m/min |
| Accuracy | : ±0.05 mm |
| Code | : G code |
| Voltage | : 380V/ 50Hz |
| Spindle capacity | : HSD 9 kw |
| Drilling shaft capacity | : 2.2 kw |
| Roller | : 2 |
| Tool magazine | : 12 |
| Spindle speed | : 6000-24000 rpm |
| Machine size | : 3500 x 2550 x 2380 mm |
| Shaft Drive Mode | : X/Y axis rack and pinion drive Z- axis screw drive |
| Servo motor | : Leadshine |
| Electric | : Siemens |
| Inverter | : Delta |
| Cylinders | : AIRTEC |
| Control system | : Weihong |
| Machine body | : Thick wall housing pipe welding plus annealing stress relief treatment |
2. Hydraulic lifting table
| Max. load | : 2 tons |
| Max. lifting height | : 1.2 M |
| Hydraulic pump motor | : 2 HP |
| Machine size | : 2200 × 1000 × 500 mm |
| Net weight | : 800 kgs |
3. Belt conveyors
| This equipment body structure is aluminum, charming and beautifull | |
| It is suitable for feeding every kind of flat workpiece | |
| Inverter speed control | |
| Width range | : 1300 mm |
| Length range | : 2500 mm |
| Loading | : 50 Kg |
