6-SPINDLE CNC HORIZONTAL DRILLING MACHINE – KW 3000 R6 2I

6-spindle CNC horizontal drilling machine – KW 3000 R6 2I is an all-in-one system that integrates multiple functions, including dowel drilling, grooving, Lamello joining, and lockset/hinge boring. With its high-speed processing capabilities, it is perfectly suited for modern furniture manufacturing workshops.

Features of 6-spindle CNC horizontal drilling machine – KW 3000 R6 2I

Equipped with 6 motors, providing maximum flexibility for diverse workpiece processing.
Fast operation speeds coupled with a user-friendly control system for effortless operation.
Superior finish quality, ensuring all processed products achieve high aesthetic appeal and structural perfection.

Specifications of 6-spindle CNC horizontal drilling machine – KW 3000 R6 2I

Working Table Size	3000 × 500 mm
Auxiliary Table Size	400 × 600 mm
X-Axis Travel	2800 mm
Y-Axis Travel	120 mm
Z-Axis Travel	50 mm
X, Y, Z Axis Transmission	Rack and Pinion, Ball Screw
Servo Motor	0.75 kW × 3 – XINTE
Spindle Motor	3.5 kW × 4, 2.2 kW × 2
Inverter	4 kW – DELTA
Dimensions	3800 × 1500 × 1500 mm
Weight	1000 kg

Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
