5-axis 3d CNC wood lathe – KW 0415 FT serves as a versatile machining solution tailored for wooden components with curved profiles and complex 3D shapes, including table legs, chair legs, staircase balusters, and decorative interior parts. 5-Axis Working Configuration: Allows flexible execution of turning, milling, drilling, and grooving operations all on a single setup.
Features of 5-axis 3d CNC wood lathe
- The 5-axis design enables the machine to easily process 3D curved profiles, such as table and chair legs. It performs a wide range of functions, including milling, turning, grooving, and drilling.
- A high-power motor ensures rapid processing speeds, thereby boosting productivity.
- The user-friendly control interface allows for easy operation.
- Servo motors are utilized to ensure high precision.
- The robust machine structure ensures durability and minimizes vibration during the machining process.
Specifications of 5-axis 3d CNC wood lathe
| Processing Length | : 1200 mm |
| Round Workpiece Diameter | : 350 mm |
| Square Workpiece Dimensions | : 500 mm |
| X-Axis Travel | : 1300 mm |
| Y-Axis Travel | : 600 mm |
| Z-Axis Travel | : 350 mm |
| Maximum Rapid Traverse Speed | : 50 m/min |
| Maximum Processing Speed | : 20 m/min |
| Motor Power | : 5.5 kW, 3.7 kW |
| X-Axis Servo Motor | : 1.2 kW |
| Y-Axis Servo Motor | : 1.2 kW |
| Z-Axis Servo Motor | : 1.0 kW |
| B-Axis Servo Motor | : 1.5 kW |
| A-Axis Servo Motor | : 5.5 kW |
| B-Axis Rotation Angle | : 360° |
| Workpiece Feeder | : 1 unit |
| Sanding Unit | : 1 unit (optional) |
| Sanding Spindle Power | : 0.75 kW (optional) |
| Working Air Pressure | : 0.6 – 0.8 MPa |
| Rated Voltage | : 380 V / 50 Hz |
| Overall Dimensions (L×W×H) | : 3300 × 2100 × 2500 mm |
| Machine Weight | : Approx. 3000 kg |
Note: Technical specifications, design features, and machine colors are subject to change without prior notice. However, such changes will not affect the machine’s functionality, performance, or operating capabilities.
View more: 2-AXIS CNC lathe with 4-station rotary tool turret and automatic material feeding – SMQH 1500/2 4KAF
Where to Buy a 5-Axis 3D CNC Wood Lathe?
CNC wood lathes are increasingly widely adopted across modern furniture workshops and manufacturing plants, particularly for businesses seeking high productivity, exceptional precision, and versatile product design capabilities.
Capitalizing on industry trends and backed by over 23 years of experience in woodworking machinery and manufacturing solutions, Quoc Duy continuously introduces advanced machining technologies—including 3D CNC turning and milling, multi-axis CNC systems, rotary table turning-milling centers, and modern automation solutions. Every machine is carefully evaluated and selected by our team based on specific product profiles, plant scale, and actual production demands, ensuring clients make the right technological investment for long-term operational efficiency.
For in-depth technical consultation on CNC lathes, 3D turning-milling technology, or specialized woodworking machinery, please contact Quoc Duy using the details below to receive expert guidance and tailored solutions.
- Email : info@quocduy.com.vn
- Hotline : +84 903 600 113
You are also welcome to visit our showroom and experience the machine in operation at: 401 To Ngoc Van Street, Thoi An Ward, Ho Chi Minh City, Vietnam.
