2 side sander features a sanding shaft that moves up and down rhythmically, which helps in smoothing both sides of the workpiece at a high speed.
Introduction of 2 side sander
Features of double sided sander
- The GF 506U is a two-sided curved edge sanding machine specifically designed for sanding chair legs.
- This Taiwanese sanding machine is capable of performing sanding operations on both sides of the product.
Specifications of double sided sander
Sanding belt drive motor | 1 HP x 2 pcs |
Sanding belt speed | 0 – 565 m/min |
Sanding belt size | 150 x 750 mm |
Sanding drum size | Ø 150 x 152 mm |
Sanding belt oscillating horsepower | Air system |
Sanding belt oscillating horsepower size | 0 -100 mm |
Feeding motor | ¼ HP x 4 pcs |
Feeding speed | 0 -21 m/min |
Feeding roller size | Ø 75 x 75 mm |
Feeding roller number | 4 pcs |
Working thickness | 15- 75 mm |
Working height | 25 – 140 mm |
Working length | 220 – 1500 mm |
Machine size | 1350 x 800 x 1400 mm |
Net weight | 570 kg |
Video of operation of the 2-side curved edge sanding machine for chair legs
Latest 2 side sander price
If you have any questions regarding the 2 side sander Taiwan, feel free to contact us for a fast consultation and a quote.
- You can reach us via email at info@quocduy.com.vn, or by calling our hotline at 0903 600 113
- You can also visit our website at www.quocduy.com.vn – www.semac.com.vn for more information.
- Additionally, you are welcome to visit our factory located at 401 To Ngoc Van, Thanh Xuan Ward, District 12, Ho Chi Minh City.
Here, you can witness the operation of other modern woodworking machine and learn how to operate the edge sanding machine yourself.
