100 ton hydraulic cold press machine TA48A-100T/10
Introduction of 100 ton hydraulic cold press machine
Feature
– This machine is mainly used to re-press and form various glued wood parts in usual temperature.
– The pressing machinery has many characteristics as good splicing effect, fast high efficiency which is widely used in furniture manufacturing industry and ply wood producing industry.
– The press quality is good, speed-fast and high efficient
Specifications
| Dimension of the platen | : 2500 x 1300 mm |
| Max. pressure | : 100 t |
| Max. opening | : 1000 mm |
| Rolling device | : 4 |
| Support capacity rolling | : 2000 kg |
| Installed power | : 5.5 kw |
| Overall dimensions | : 3000 x 1300 x 3280 mm |
| Net weight | : 3000 kg |
See more: Cold press equipment
