The single spindle cnc router machine – SMJM 1325 B1 is the ultimate solution for woodworking with high precision and stable performance. Featuring a robust frame design, a convenient vacuum table, and a powerful spindle motor, this machine flexibly meets various demands such as cutting, milling, and drilling on a wide range of materials. It is the ideal choice for small-scale furniture workshops.
Features of the single spindle cnc router machine
Multifunctional Integration: This machine integrates various functions such as cutting and milling, equipped with a powerful 6kW spindle motor and a rotation speed of up to 18,000 RPM.
Heavy-Duty Structure: The machine frame is engineered for maximum rigidity, ensuring high stability and minimizing vibrations during the machining process.
Advanced Vacuum System: The working table utilizes a high-efficiency vacuum suction system, powered by a 5.5kW vacuum pump motor.
User-Friendly Design: The system is intuitively designed for easy operation and effortless control.
Technical specifications of the single spindle cnc router machine
| Working table size | : 1300 x 2500mm |
| X-axis travel | : 1400mm |
| Y-axis travel | : 2500mm |
| Z-axis travel | : 230mm |
| Spindle motor | : 6 kW |
| Spindle speed | : 18,000 rpm |
| Vacuum pump | : 5.5 kW, dry vacuum pump |
| Positioning accuracy | : ±0.05mm |
| Transmission method | : X, Y (rack and pinion), Z (ball screw), linear guideways |
| Voltage | : 3-phase 380V/50Hz |
| Total power | : 13.5 kW |
| NET weight | : 1100kg |
| Electrical cabinet size | : 750 x 600 x 1100mm |
| Machine dimensions (LxWxH) | : 3060 x 2100 x 1600mm |
Note: Technical specifications, design features, and machine color are subject to change without prior notice, but this will not affect the machine’s functions and operational capabilities.
