CNC router machine with boring unit autoload – SM 1325 R1BP AL is specialized for cutting and drilling all kinds of industrial boards, mdf, mfc, hdf, polywood boards, …
What is CNC router machine with boring unit autoload?
1. CNC router machine with boring unit autoload
Features of CNC router machine with roller
-
CNC router machine with roller equipped with 2 additional rollers to firmly fix the workpiece when needing to process small sized products or boards with uneven surfaces such as polywood.
-
The CNC router nesting machine is equipped with a High Power Milling and Drilling Motor for high speed and precision machining – Rapidly improving productivity.
-
Automatic knife change mechanism, with 12 straight knife trays.
-
The automatic lubrication system helps increase the life of the machine.
Specifications of CNC router machine with roller
| X axis stroke | : 1300mm |
| Y axis stroke | : 2500mm |
| Z axis stroke | : 220mm |
| Working speed | : 0-60m/min |
| Accuracy | : ±0.05mm |
| Code | : G code |
| Voltage | : 380V/50Hz |
| Spindle capacity | : 9 kw |
| Drilling shaft capacity | : 2.2 kw |
| Roller | : 2 pcs |
| Tool magazine | : 12 pcs |
| Spindle speed | : 6000-24000 rpm |
| Machine size | : 3500 x 2550 x 2380 mm |
| Shaft Drive Mode | : X/Y axis rack and pinion drive Z- axis screw drive |
| Servo motor | : Leadshine |
| Electric | : Siemens |
| Inverter | : Delta |
See more:
2. Hydraulic lift table
Features of hydraulic lift table
- Maximum workpiece load of 2 tons supports effective workpiece lifting.
- The hydraulic lift table combined with the CNC machine with roller board picker with workpiece roller will bring outstanding productivity.
Specifications of hydraulic lift table
| Maximum load | : 2 ton |
| Maximum lifting height | : 1200mm |
| Hydraulic pump motor | : 2HP |
| Net Weight | : 800 kg |
| Size machine | : 2200 × 1000 × 500 mm |
3. Workpiece output conveyor
| Workpiece feeding width | : 1300mm |
| Embryo insertion length | : 2500mm |
| Workpiece weight | : 50 Kg |
Quoc Duy is always confident to be one of the leading units in the industry providing woodworking machines in general and CNC nesting machines in particular. With nearly 20 years of experience in the industry, coming to Quoc Duy you will receive the most professional and dedicated service.
- Email: info@quocduy.com.vn
- Hotline: 0903 600 113
- Website: www.quocduy.com.vn – www.semac.com.vn
You can also come directly to our factory at: 401 To Ngoc Van, Thanh Xuan Ward, District 12, Ho Chi Minh City to see the operating process of the most modern machines.
