Acoustic Panel Drilling Machine - SMBL 1230 D4

The acoustic panel drilling machine is a highly worthwhile investment if you are looking for a fast, precise, and aesthetically pleasing acoustic hole drilling solution. Featuring a heavy duty structure, a stable motor system, and exceptional accuracy, this equipment effectively meets the large scale production demands of acoustic panels, soundproofing walls, and furniture, helping to optimize productivity and significantly shorten processing times.

Features of the Acoustic Panel Drilling Machine

This multi spindle drilling machine is engineered specifically for production lines manufacturing high end acoustic panels, soundproofing walls, and premium furniture.
The machine can drill hundreds of holes simultaneously on the wooden surface with absolute precision, saving up to 70% of processing time compared to traditional methods.
The heavy duty machine frame is constructed from solid cast steel to minimize vibration during operation, ensuring outstanding stability and long term durability.
A high power motor system combined with a powerful vacuum clamping mechanism securely stabilizes the workpiece to deliver crisp, uniform drill holes without damaging the material surface.
An intelligent touch screen control panel allows operators to easily customize parameters, select drilling modes, and monitor the entire process with just a few touches.
This advanced system helps businesses significantly boost production efficiency while maintaining consistent quality across every acoustic product.

Technical Specifications of the Acoustic Panel Drilling Machine

Motor power	2.2 kW x 16
Vacuum pump motor power	7.5 kW
Hydraulic motor power	3.75 kW
Drilling length	3000 mm
Working width	1220 mm
Drilling depth	35 mm
Drill hole diameter	φ2 mm – φ12 mm
Working pressure	0.6 – 0.8 MPa
Machine dimensions	4300 x 2300 x 1800 mm
Machine weight	3500 kg

Note: Technical specifications, design features, and machine colors are subject to change without prior notice; however, any modifications will not alter the primary functions and performance capabilities of the machine.

Where to Invest in an Acoustic Panel Drilling Machine at the Best Price?

With over 22 years of accompanying the Vietnamese woodworking industry, Quoc Duy takes pride in being a pioneer that delivers modern technological solutions to help businesses accelerate production, optimize productivity, and guarantee product quality.

Far beyond simply supplying machinery, Quoc Duy’s highly skilled engineering team directly calibrates and conducts real world test runs at the workshop before final delivery, ensuring the equipment operates stably, accurately, and durably under all manufacturing conditions.
